How do you remove and install the Steering Knuckle on Acura TL?

To remove the components, first loosen the wheel lugnuts, raise the front of the vehicle, and securely support it on jackstands before removing the wheels. Next, remove the driveaxle/hub nut, detach the brake hose bracket from the steering knuckle, and remove the brake caliper, hanging it out of the way with a piece of wire. Then, remove the caliper mounting bracket if equipped, followed by the two mounting screws that retain the brake disc to the hub, and then take off the brake disc. After that, remove the ABS wheel speed sensor, disconnect the tie-rod end from the steering knuckle, and separate the lower control arm from the balljoint at the bottom of the steering knuckle. Proceed to separate the upper end of the knuckle from the upper control arm balljoint while keeping it supported. Carefully pull the knuckle and hub assembly off the driveaxle, tapping on the end of the driveaxle with a soft-face hammer if necessary, and support the driveaxle with a piece of wire to prevent damage to the inner CV joint, being cautious not to overextend it. If the wheel bearing needs replacement, take the steering knuckle/hub assembly to a qualified repair facility for the bearing to be pressed out and a new one pressed in. For installation, apply a light coat of wheel bearing grease to the driveaxle splines, insert the driveaxle through the splined bore of the hub while guiding the steering knuckle into position, and connect the upper end of the knuckle to the upper control arm balljoint, tightening the balljoint stud nut to the specified torque and installing a new cotter pin. Next, connect the balljoint on the bottom of the knuckle to the lower control arm, tightening the nut to the specified torque and installing a new cotter pin. Attach the brake disc to the hub, install the disc retaining screws, and tighten them securely. Install the caliper mounting bracket if equipped and the caliper, tightening the bolts to the proper torque, then attach the brake hose bracket to the knuckle and tighten the bolts securely. Install the driveaxle/hub nut and tighten it to the specified torque, re-staking it with a punch or blunt chisel. Finally, install the wheel and lug nuts, lower the vehicle, and tighten the lug nuts to the specified torque.

Genuine Acura TL Steering Knuckle

Front Steering Knuckle

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

19 Steering Knuckles found

View related parts
Acura TL Right Front Knuckle
Part Number: 51210-SEP-A11
$464.30 MSRP: $663.10
You Save: $198.80 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle, Right Front; Knuckle
- Position: Front Passenger Side
- Replaces: 51210-SEP-A10
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2004-2008 Acura TL
View related parts
Acura TL Left Front Knuckle
Part Number: 51215-SEP-A11
$464.30 MSRP: $663.10
You Save: $198.80 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle, Left Front; Knuckle
- Position: Front Driver Side
- Replaces: 51215-SEP-A10
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2004-2008 Acura TL
View related parts
Acura TL Driver Front Spindle Knuckle
Part Number: 51215-SEP-A01
$464.30 MSRP: $663.10
You Save: $198.80 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle, Left Front; Knuckle
- Position: Front Driver Side
- Replaces: 51215-SEP-A00
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2004-2008 Acura TL
View related parts
Acura TL Rear Left Spindle Knuckle Hub Bearing
Part Number: 52215-TK5-A00
$238.57 MSRP: $340.72
You Save: $102.15 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle, Left Rear (4Wd); Knuckle
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2009-2014 Acura TL
View related parts
Acura TL Knuckle, Left Rear
Part Number: 52215-SEP-A00
$314.74 MSRP: $449.50
You Save: $134.76 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2004-2005 Acura TL
View related parts
Acura TL Left Front Knuckle
Part Number: 51215-TK4-A00
$594.21 MSRP: $848.63
You Save: $254.42 (30%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Knuckle, Left Front; Knuckle
- Position: Front Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2009-2014 Acura TL
View related parts
Acura TL Left Rear Knuckle
Part Number: 52215-SEP-A10
$314.74 MSRP: $449.50
You Save: $134.76 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle, Left Rear; Knuckle
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2006-2008 Acura TL
View related parts
Acura TL Left Rear Knuckle
Part Number: 52215-S0K-A00
$610.16 MSRP: $983.12
You Save: $372.96 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle, Left Rear; Knuckle
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1999-2003 Acura TL
View related parts
Acura TL Right Front Knuckle
Part Number: 51210-S4K-A00
$394.04 MSRP: $562.75
You Save: $168.71 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle, Right Front; Knuckle
- Position: Front Passenger Side
- Replaces: 51210-S84-305, 51210-S84-A00, 51210-S84-A01, 51210-S84-A02
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1999-2003 Acura TL
View related parts
Acura TL Left Rear Knuckle (2Wd)
Part Number: 52215-TK4-A00
$238.57 MSRP: $340.72
You Save: $102.15 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Knuckle, Left Rear (2Wd); Knuckle
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2009-2014 Acura TL
View related parts
Acura TL Right Front Knuckle
Part Number: 51210-TK4-A00
$594.21 MSRP: $848.63
You Save: $254.42 (30%)
Product Specifications
- Other Name: Knuckle, Right Front; Knuckle
- Position: Front Passenger Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2009-2014 Acura TL
View related parts
Acura TL Left Rear Knuckle
Part Number: 52116-SZ5-000
Product Specifications
- Other Name: Knuckle, Left Rear; Knuckle
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1996-1998 Acura TL
View related parts
Acura TL Right Front Knuckle
Part Number: 51210-SZ5-900
Product Specifications
- Other Name: Knuckle, Right Front; Knuckle
- Position: Front Passenger Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1996-1998 Acura TL
View related parts
Acura TL Left Front Knuckle
Part Number: 51215-SZ5-900
Product Specifications
- Other Name: Knuckle, Left Front; Knuckle
- Position: Front Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1996-1998 Acura TL
View related parts
Acura TL Right Front Knuckle (Abs)
Part Number: 51210-SW5-J60
Product Specifications
- Other Name: Knuckle, Right Front (Abs); Knuckle
- Position: Front Passenger Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1995-1998 Acura TL
View related parts
Acura TL Left Front Knuckle (Abs)
Part Number: 51215-SW5-J60
Product Specifications
- Other Name: Knuckle, Left Front (Abs); Knuckle
- Position: Front Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1995-1998 Acura TL
View related parts
Acura TL Left Rear Knuckle
Part Number: 52116-SL5-910
Product Specifications
- Other Name: Knuckle, Left Rear ; Spindle; Knuckle, Spindle
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1995-1998 Acura TL
View related parts
Acura TL Left Front Knuckle
Part Number: 51215-S4K-A00
Product Specifications
- Other Name: Knuckle, Left Front; Knuckle
- Position: Front Driver Side
- Replaces: 51215-S84-A01, 51215-S84-A00, 51215-S84-A02, 51215-S84-305
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 1999-2003 Acura TL
View related parts
Acura TL Steering Knuckle
Part Number: 51210-SEP-A01
$464.30 MSRP: $663.10
You Save: $198.80 (30%)
Product Specifications
- Other Name: Knuckle, Right Front; Knuckle
- Position: Passenger Side
- Replaces: 51210-SEP-A00
- Warranty: This genuine part is guaranteed by Acura's factory warranty.
Fits for 2004-2008 Acura TL

Acura TL Steering Knuckle

We provide a broad range of OEM Acura TL Steering Knuckle at unbeatable prices on our website. For your OEM parts, You can count on the guaranteed quality, manufacturer's warranty, outstanding customer service, and prompt delivery. We look forward to your visit.

Acura TL Steering Knuckle Parts Questions & Experts Answers

Driver Front Spindle Knuckle
51215-SEP-A01
Q: How do you remove and install the Steering Knuckle on Acura TL?
A: To remove the components, first loosen the wheel lugnuts, raise the front of the vehicle, and securely support it on jackstands before removing the wheels. Next, remove the driveaxle/hub nut, detach the brake hose bracket from the steering knuckle, and remove the brake caliper, hanging it out of the way with a piece of wire. Then, remove the caliper mounting bracket if equipped, followed by the two mounting screws that retain the brake disc to the hub, and then take off the brake disc. After that, remove the ABS wheel speed sensor, disconnect the tie-rod end from the steering knuckle, and separate the lower Control Arm from the balljoint at the bottom of the steering knuckle. Proceed to separate the upper end of the knuckle from the upper control arm balljoint while keeping it supported. Carefully pull the knuckle and hub assembly off the driveaxle, tapping on the end of the driveaxle with a soft-face hammer if necessary, and support the driveaxle with a piece of wire to prevent damage to the inner CV joint, being cautious not to overextend it. If the wheel bearing needs replacement, take the steering knuckle/hub assembly to a qualified repair facility for the bearing to be pressed out and a new one pressed in. For installation, apply a light coat of wheel bearing grease to the driveaxle splines, insert the driveaxle through the splined bore of the hub while guiding the steering knuckle into position, and connect the upper end of the knuckle to the upper control arm balljoint, tightening the balljoint stud nut to the specified torque and installing a new cotter pin. Next, connect the balljoint on the bottom of the knuckle to the lower control arm, tightening the nut to the specified torque and installing a new cotter pin. Attach the brake disc to the hub, install the disc retaining screws, and tighten them securely. Install the caliper mounting bracket if equipped and the caliper, tightening the bolts to the proper torque, then attach the brake hose bracket to the knuckle and tighten the bolts securely. Install the driveaxle/hub nut and tighten it to the specified torque, re-staking it with a punch or blunt chisel. Finally, install the wheel and lug nuts, lower the vehicle, and tighten the lug nuts to the specified torque.
